4.6L Triton V8 Engine for Sale | OEM Ford Modular V8 (281 cu in)
$2,599.00
Product Overview
- Displacement: 4.6L (281 cu in)
- Engine Family: Ford Modular V8
- Configuration: V8 OHC, 16 to 32 valves by variant
- Horsepower: 215 to 390 hp by variant
- Condition: OEM used, compression tested and inspected
- Availability: 2V, 3V, and 4V variants in stock
- Shipping: Free crated freight to all 50 states, 5 to 10 business days
- All 8 cylinders compression tested with results shared before payment
- Variant (2V, 3V, or 4V) confirmed before shipping
- Year and casting numbers documented
- Spark plug thread condition inspected, critical 3V issue
- Timing chain tensioner condition inspected
- 100% fitment verified before every order ships
- Zero core charge required, your existing engine stays with you
- Backed by a 15 day replacement warranty against internal defects
Did you like this product? Add to favorites now and follow the product.
(+800) 1234 5678 90 Start Live Chat
Description
Engine Background
The 4.6L Triton is the most widely produced engine in Ford’s modular V8 family, made from 1991 to 2014 across passenger cars, full-size trucks, performance Mustangs, and luxury sedans. It produced as little as 215 horsepower in early F-150 base trim and as much as 390 horsepower in the Mach 1 4V DOHC, all from the same 281 cubic inch displacement. The aluminum (or iron, in truck applications) block uses 90 millimeter bore and 90 millimeter stroke, near-square geometry that gives the 4.6 Triton its smooth power delivery and high-rpm willingness.
Three Cylinder Head Variants You Must Know Before Ordering
The 4.6 Triton came in three distinct cylinder head designs that affect both power output and parts compatibility. 2V uses two valves per cylinder with a single overhead cam, found on base F-150, base Mustang GT (1996 to 2004), Crown Victoria, Town Car, and Grand Marquis. 3V adds a third valve and Variable Cam Timing, found on later F-150 (2005 to 2010), Mustang GT (2005 to 2010), and Explorer V8. 4V DOHC uses four valves per cylinder with dual overhead cams, found on Mustang Cobra, Mach 1, Bullitt, Lincoln Mark VIII, and Mercury Marauder. Always specify the variant when ordering.
Why Ford Owners Choose a Used 4.6 Triton
The 4.6 Triton is one of the most-supported V8 engines in the aftermarket, and clean used cores are widely available because Ford built millions of them. For F-150 owners, Crown Vic restorers, Mustang GT builders, and Town Car maintainers, a tested used unit costs less than half of a remanufactured long block while delivering excellent service life when properly inspected.
When Replacement Becomes Necessary
- Spark plug blow-out with damaged threads (the famous 2V and 3V issue), critical inspection point
- Timing chain rattle on cold start, tensioner failure (common past 100,000 miles)
- Knock or rattle under load, rod or main bearing wear
- Coolant in oil, intake manifold gasket failure (early aluminum manifolds)
- Misfire codes from one or more cylinders, head gasket or valve seat failure
- Loss of power on 3V engines with VCT codes, cam phaser wear
- Low oil pressure, oil pump or main bearing wear
Known Issues We Document Before Shipping
- Spark plug thread condition, the most common 2V and 3V failure point (we test thread integrity)
- Timing chain tensioner operation, wear is normal past 100,000 miles
- Cam phaser operation on 3V variants, VCT-related codes
- Intake manifold condition (early units had cracking issues with original plastic manifold)
- Block casting numbers and date code documented
- Variant (2V / 3V / 4V) confirmed and photographed for every order
What Ships and What Does Not
| INCLUDED | Long block: block, crankshaft, rods, pistons, camshafts, heads, valve train, oil pan, valve covers, timing cover, timing chain. |
|---|---|
| NOT INCLUDED | Intake manifold (sometimes included on truck variants), throttle body, ignition coils, plugs, ECU, harness, alternator, starter, A/C, power steering, flexplate, motor mounts. |
| Fluids | Drained before shipping. Refill with Motorcraft 5W-20 (most variants) or 5W-30 (truck variants and pre-2003) full synthetic motor oil. |
| Core Note | No core charge. You are not required to return your old engine. |
Direct-Fit Vehicle Applications
The 4.6L Triton was a direct fit in the following vehicles:
| Ford F-150 | 1997 to 2010 (2V early, 3V from 2005) |
|---|---|
| Ford Mustang GT | 1996 to 2010 (2V through 2004, 3V from 2005) |
| Ford Mustang Cobra | 1996 to 2004 (4V DOHC) |
| Ford Mustang Mach 1 | 2003 to 2004 (4V DOHC) |
| Ford Mustang Bullitt | 2001 (4V DOHC equivalent) |
| Ford Crown Victoria | 1992 to 2011 (2V) |
| Ford Expedition | 1997 to 2004 (2V) |
| Ford Explorer Sport Trac | 2003 to 2010 (2V and 3V) |
| Ford Explorer | 2002 to 2010 (4V DOHC and 2V) |
| Lincoln Town Car | 1992 to 2011 (2V) |
| Lincoln Continental | 1995 to 2002 (4V DOHC InTech) |
| Lincoln Mark VIII | 1993 to 1998 (4V DOHC InTech) |
| Lincoln Aviator | 2003 to 2005 (4V DOHC) |
| Mercury Grand Marquis | 1992 to 2011 (2V) |
| Mercury Cougar | 1994 to 1997 (2V) |
| Mercury Marauder | 2003 to 2004 (4V DOHC) |
| Ford E-Series Vans | 1997 to 2014 (2V) |
Transmission pairings: Ford 4R70W and 4R75W 4-speed automatic (most cars and trucks), 5R55E 5-speed automatic (Explorer), Tremec T-45 and TR-3650 5-speed manual (Mustang), Tremec T-56 6-speed manual (Cobra and Mach 1). Tell us your transmission for confirmation.
Inspection Workflow
Every used 4.6L Triton we ship goes through this process:
- Compression test across all 8 cylinders with pressure per cylinder recorded
- Spark plug thread integrity tested, the critical 2V and 3V wear point
- Timing chain tensioner operation verified
- Cam phaser operation tested on 3V variants
- Visual inspection of block deck, head surfaces, oil galleries
- Variant (2V / 3V / 4V) photographed and confirmed
- Year, casting numbers, donor mileage documented when available
Mileage varies by donor unit. Where verified mileage is available, it is shared. Where mileage cannot be confirmed, we disclose openly before payment. Full inspection notes available on request.
Why Buy From Part Nests
- All 8 cylinders compression-tested with results shared before payment
- Variant (2V, 3V, or 4V DOHC) confirmed and photographed
- Spark plug thread condition tested, the critical Triton wear point
- Timing chain tensioner and cam phaser inspected
- Year and casting numbers documented for every unit
- Free crated freight to all 50 states, no hidden fees
- No core return required
- 15 day replacement warranty on internal defects
- Call (240) 306-7051 to speak with someone who knows 4.6 Triton 2V vs 3V vs 4V differences, spark plug thread service planning, and Ford modular cam phaser inspection
Additional information
| engine-family | Ford Modular V8 |
|---|---|
| configuration | 16 to 32 valves by variant, V8 OHC |
| displacement | 4.6L (281 cu in) |
| bore-x-stroke | 90.2 mm x 90.0 mm |
| compression-ratio | 9.0:1 to 10.0:1 by variant |
| aspiration | Naturally Aspirated |
| variants | 2V SOHC, 3V SOHC with VCT, 4V DOHC |
| fuel-system | Sequential Multi-Point Injection |
| fuel-type | Regular Unleaded (4V DOHC prefers premium) |
| block-material | Aluminum (most) or cast iron (truck) |
| head-material | Aluminum |
| firing-order | 1-3-7-2-6-5-4-8 |
| production-years | 1991 to 2014 |
| horsepower | 215 to 390 hp by variant |
| torque | 270 to 320 lb-ft by variant |
| compatible-transmissions | 4R70W, 4R75W, 5R55E, T-45, T-56, TR-3650 |
| condition | compression tested and inspected, Used OEM |
Cylinder head valve count and architecture. 2V uses two valves per cylinder with a single overhead cam, found on base F-150, base Mustang GT (1996 to 2004), Crown Victoria, Town Car, and Grand Marquis. 3V adds a third valve and Variable Cam Timing, found on later F-150 (2005 to 2010), Mustang GT (2005 to 2010), and Explorer V8. 4V DOHC uses four valves per cylinder with dual overhead cams, found on Mustang Cobra, Mach 1, Bullitt, Lincoln Mark VIII, and Mercury Marauder. The three variants share a block but have completely different heads, intakes, accessory drives, and ECU calibrations.
The 2V and 3V cylinder heads have a known issue with spark plug threads stripping or plugs blowing out under combustion pressure, particularly when over-torqued or under-torqued at installation. The aluminum head's shallow plug threads are the design weakness. Aftermarket thread inserts (Time-Sert, Helicoil, or Ford's own kit) repair this without head removal. We test thread integrity on every 4.6 Triton before shipping.
The 3V variant uses Variable Cam Timing actuators (cam phasers) on each cam to adjust valve timing in real time. The phasers can develop internal wear that produces characteristic ticking noise and VCT-related fault codes. Phaser replacement is a known 3V service item, typically done with new timing chains as a set. We inspect phaser operation on every 3V we ship.
Depends on year and variant. The 1996 to 2004 Mustang GT used the 2V Triton. The 2005 to 2010 Mustang GT used the 3V Triton. They are not directly interchangeable. The 2V GT and 3V GT use different intake manifolds, accessory drives, ECU calibrations, and oil pans. Match the variant to your specific Mustang GT year.
No. The 2V intake manifold has different bolt patterns and port shapes than the 3V intake. The 3V uses smaller ports designed for the 3V head's improved breathing characteristics. Cross-installing requires different manifolds and is not a direct bolt-on swap.
Different Mustang and Lincoln applications. The 1996 to 2004 Mustang Cobra and 2003 to 2004 Mach 1 use the 4V Aluminator-related 4.6L producing 300 to 390 hp. The 1993 to 1998 Lincoln Mark VIII and 1995 to 2002 Lincoln Continental use the 4V InTech 4.6L producing 270 to 300 hp. The 2003 to 2004 Mercury Marauder uses the 4V Marauder variant. The 4V heads share architecture but specific calibration and supporting hardware differ.
Yes for 1992 to 2011 Crown Victoria. The Crown Vic used the 2V Triton for its entire production run. Same engine as Town Car and Grand Marquis. Police Interceptor variants have slightly different calibration. Match year for transmission compatibility.
No. There is no core return required.
15 Day Replacement Warranty
Every used 4.6L Triton engine purchased through Part Nests carries a 15 day replacement warranty starting on the delivery date.
What Is Covered
- Internal defects already present when the engine arrives
- Performance materially different from how the engine was described
- Incorrect part shipped due to an error on our end
What Is Not Covered
- Damage caused during installation
- Damage from incorrect spark plug torque (a known 2V and 3V failure trigger)
- Damage from skipped timing chain service at install on high-mileage units
- External components unless specifically itemized
- Labor expenses of any kind
To start a warranty claim, reach us within 15 days of delivery at (240) 306-7051.
- Variant Confirmed: 2V, 3V, or 4V DOHC photographed before payment
- Spark Plug Threads Tested: Critical 2V and 3V wear point evaluated
- Timing Chain Inspected: Tensioner operation verified before shipping
- Cam Phaser Checked: 3V VCT actuator condition assessed
- All 8 Cylinders Tested: Compression results shared before payment
- 15 Day Replacement Cover: Internal defects protected from delivery onward
